129
MAINTENANCE
Choke Adjustment Procedu re 4-cycle Engines
Push/Pull Choke
1. Locate the boot behind the
choke knob and pull it
back. Loosen the friction
nut 1 turn or until choke
slides freely. Re-install
boot.
2. Push the choke knob in to
the full off position.
3. Slide boots off in-lin e cable adjuster and loosen adjustment
locknut.
4. Turn adjuster until the choke knob pushes out over 1/4″.
5. Push on the choke knob lightly while turnin g the adjuster the
opposite way.
6. Turn the adjuster until the knob contacts the boot.
7. Tighten adjuster locknut.
8. Slide boots back over the cable adjuster until they touch at the
middle of the adjuster.
9. Pull back the choke knob boot and tighten the friction nut until
the choke will maintain a set position. Re-install boot.
Boot
Adjuster
Sleeve
Locknut
Boot
