2.6.1 If the hose is too long = Cut the feed hose
• Don't cut the lead hose : it must stay the equal to the depth of the pool, see "2.3 I Adjus ng
the lead hose".
• Remove the quick disconnect from the suc on port : simultaneously unscrew and pull. See picture
.
• Unscrew the swivel to separate the feed hose into two equal sec ons, see picture
: simultaneously unscrew and pull.
and
.
• Cut the excess length, for example : 0.50 cm, by removing the same amount from each of these two sec ons, i.e.
0.25 cm on each sec on (in the example shown), see picture
, by removing the same amount from each of these two sec ons,
.
• Assemble the two feed hose's sec ons using the swivel and a ach clamps, see picture .
• Adjust the distance between each oat on the feed hose; the recommended distance between each oat is 45 to
90 cm. Slide the oats on the hose to posi on them, see picture
Adjust the distance between each oat on the feed hose; the recommended distance between each oat is
.
Suc on port
connec on
Lead hose
connec on
Feed hose (sec on 1)
Feed hose (sec on 2)
0.25 cm
(for exemple)
0.25 cm
(for exemple)
Recommended
Lead hose
connec on
Suc on
port
connec on
Feed hose (sec on 1)
Feed hose (sec on 2)
2.6.2 If the hose is too short = add a sec on of feed hose
• Purchase an addi onal hose sec on, a swivel and two hose a ach clamps from your retailer.
• Cut the new sec on if necessary, see "2.6.1 If the hose is too long = Cut the feed hose".
