1.2 I Technical speci ca ons and parts list
1.2.1 Technical speci ca ons
P280 P380 P3900 Sport
Energy source Booster pump coupled to the ltra on system
Working pressure 2.2 bar 1.8 bar Maximum 2.2 to 2.6 bar
Feed hose and Lead hose assembly
length
9.60 m
Largeur de la bouche d'aspira on (cm) 7 cm 6 cm
Minimum power required by the
booster pump
1 HP (if the distance from the equipment room is < 15 metres)
1.5 HP or more (if the distance from the equipment room is > 15
metres)
1.2.2 Cleaner marking
: Filter bag
: Head oat
: Cleaner body
: Sweep hose
: Sweep hose cleaning brush
: Suc on hose
: Filter bag clamping clip (P280/P380)
: Se ng the thrust jet
: Adjus ng screw of the sweep hose
1.2.3 Hoses marking
Suc on port
Cleaner
: Lead hose (marked "Polaris Lead Hose")
: Feed hose (marked "Polaris")
: Swivel N°1
: Swivel N°2
: Universal wall ng assembly UWF
: Relief valve
: Lead hose oats, spaced 60 to 90 cm apart
: Feed hose oats, spaced 45 to 90 cm apart
: In-line lter assembly
: Back-up valve
: Connec on kit (P3900 Sport) or a ach clamp (P280/P380)
