Polaris PB4SQ Replacement Instructions

Page 4
Section 3. contentS
Please ensure that you have all the parts included on this list for your
replacement Kit. If any parts are missing or damaged please contact
Polaris Technical support at 1-800-822-7933 or visit www.polarispool.com .
ITEM Part# Description QTY
1 R0722900
Capacitor Housing Cover 1
Hex Screw 6-32 X 1/2 4
Screw Retention Washer 4
2 R0734500
Capacitor, 30 mfd, 400VAC 1
3 R0734200
Motor Assembly, 725 WATT 1
4 R0722600
Fan Cover 1
Hex Screw 6-32 X 3/8 2
Star Washer 1
Motor Fan 1
Snap Ring 1
Bonding Lug 1
5 R0723000
Motor Fan 1
Snap Ring 1
6 R0722700
Base 1
7 R0747800
Spring Drive Band 1
Ceramic Mating Ring 1
8 R0723200
Spring Drive Band 1
Ceramic Mating Ring 1
Back Plate 1
Pump Housing O-Ring 1
Diffuser O-Ring First Stage (Orange) 1
9 R0734300
Spring Drive Band 1
Ceramic Mating Ring 1
Pump Housing O-Ring 1
Diffuser O-Ring First Stage (Orange) 1
Drain Plug & O-Ring #2-112 1
10 R0723100
Pump Housing 1
Pump Housing O-Ring 1
Diffuser O-Ring First Stage (Orange) 1
Drain Plug & O-Ring #2-112 1
11 R0722800
Stackable Impeller/diffuser stage 4
12 R0734400
Motor Shaft Locking Nut 1
Split Washer 316SS 1
Impeller Nut Washer 1
Hex Screw 3/8X16X1.125 4
Washer 3/8” SS 4
13 R0617100
Quick Connect 4
Reinforced Hose 6 ft.
14 R0621000
Quick Connect 4
15 P19
Reinforced Hose 6 ft.
Polaris
®
PB4SQ™ Booster Pump

Polaris PB4SQ Specifications

General

Type	Booster Pump
Voltage	115/230V
Max Head	60 ft
Inlet Size	1.5 inches
Outlet Size	1.5 inches
Horsepower	0.75 HP
Motor Type	TEFC
