142
Maintenance
Steering Inspectio n
The steering assembly of the ATV should be checked periodically for loose nuts and bolts.
If any are found, have your dealer tighten them before operating the ATV.
Toe Alignment
Use the following procedure to check the toe alignment of the vehicle. The recommended
toe alignment is 1/8” to 1/4” toe out.
1. Set the handlebars in a straight-ahead position. NOTE: The steering frog can be used
as an indicator of whether the handlebars are straight. The frog should always point
straight back from the steering post.
2. Place stands (A) in front of the vehicle, perpendicular to the rear tires. See illustration.
WARNING
Severe injury or death can result from improper toe alignment and adjustment. Do not
attempt to adjust tie rod alignment. All tie rod adjustments should be performed by an
authorized Polaris dealer.
