150
Maintenance
Cylinder Head/Cylinder Base Fastener Torque
Have your dealer check the ATV cylinder head and cylinder base fasteners for proper torque
at the first service or after 25 hours.
Gearcase Lubrication
The gearcase fill plug (A) is located on the top
of the gearcase. The sight glass (B) is on the
righthand side of the gearcase. The oil level
must be maintained in the safe zone of the sight
glass. It should be checked monthly and
changed annually.
With the ATV on a level surface, check the oil
level through the sight glass. If the level is low,
add AGL Synthetic Gearcase Lubricant. See
page 170 for the part numbers of Polaris
products.
B
A
