TIRE ROTATION
Tire rotation is recommended for every
500 miles (800 km) interval. Perform tire
rotation on the vehicle by following the
rearward cross strategy as shown.
AXLE AND WHEEL NUT TORQUE SPECIFICATIONS
Inspect the following items occasionally for tightness, and if they've been
loosened for maintenance service. Do not lubricate the stud.
2-Piece Flange Nut
Front and Rear
60 ft-lbs (81 N·m)
Spindle Nut
Front
110 ft-lbs (149
N·m)
Hub Retaining Nut
Rear
180 ft-lbs (244
N·m)
WHEEL REMOVAL
1. Position the vehicle on a level surface.
2. Place the transmission in PARK. Stop the engine.
3. Loosen the wheel nuts slightly.
4. Elevate the side of the vehicle by placing a suitable stand under the frame.
5. Remove the wheel nuts and washers. Remove the wheel.
135
MAINTENANCE
