SPECIFICATIONS
PRO XD STANDARD CAB
PRO XD STANDARD CAB
Maximum Weight
Capacity
1900 lb (861 kg) (including operator, passenger,
cargo, accessories)
Dry Weight 1599 lb (725 kg)
GVWR – Gross
Vehicle Weight
Rating
3600 lb (1633 kg) per ANSI/OPEI B71.9-2016,
Section 5.1.2
Fuel Capacity 11.5 gal (43.5 L)
Engine Oil Capacity 2.5 qt (2.4 L)
Coolant Capacity 5.8 qt (5.5 L)
Towing Capacity 2500 lb (1134 kg)
Hitch Tongue
Capacity
250 lb (113 kg)
Max. Cargo Box Load 1250 lb (566 kg)
Overall Length 126 in (320 cm)
Overall Width 62.5 in (158.8 cm)
Overall Height 75 in (191 cm)
Wheelbase 85 in (215.9 cm)
Cargo Box
Dimensions (Inside)
54 in (137 cm) wide, 43.5 in (110 cm) long, 11.5 in
(29 cm) high
Ground Clearance 11 in (27.9 cm)
Min. Turning Radius 112 in (284.5 cm)
Engine 4-Stroke SOHC Twin Cylinder
Displacement 999 cm
3
Bore x Stroke (93 mm) x (73.5 mm)
151
SPECIFICATIONS
