RANGER CREW 1000
Maximum Weight
Capacity (includes
weight of operator,
passenger, cargo,
accessories)
1750 lbs. (794 kg) (including operator, passengers,
cargo, accessories)
1350 lbs. (612 kg) (Models sold in California)
Dry Weight 1786 lbs. (810.1 kg)
Test GVW -
Rollover Protection
System (ROPS)
3750 lbs. (1701 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 11.35 gal (43 L)
Engine Oil Capacity 2.5 qts. (2.4 l)
Coolant Capacity 6 qts. (5.7 l)
Overall Length 152 in. (385 cm)
Overall Width 62.5 in. (159 cm)
Overall Height 75 in. (191 cm)
Wheelbase 133 in (287 cm)
Cargo Box
Dimensions (Inside)
36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 12 in (30.5 cm)
Min. Turning Radius 199 in. (507 cm)
Towing Capacity 2500 lbs. (1134 kg)
Hitch Tongue
Capacity
150 lbs. (68 kg)
Max. Cargo Box
Load
1,000 lbs (454 kg)
600 lbs (272 kg) (Models sold in California)
Engine 4-Stroke SOHC Twin Cylinder
Displacement 999 cc
Bore x Stroke (mm) 93 mm x 73.5 mm
Alternator Output 660 W @ 3000 RPM
900 W @ 3000 RPM (if equipped)
148
SPECIFICATIONS
