1. Remove the eight fasteners
q
that retain the outer clutch cover.
NOTE
Removal of left rear wheel or left rear shock is NOT necessary for belt
replacement.
2. To remove the clutch cover, pull the cover (starting at the bottom), lift up over
the suspension, and then out of the vehicle.
NOTE
Use care when lifting clutch cover upwards. Do not damage cover, intake boot,
or electrical harness.
3. Mark the drive belt direction of rotation so that it can be installed in the same
direction.
109
MAINTENANCE
