Max. Cargo Box
Load
1,000 lbs (454 kg)
600 lbs (272 kg) (Models sold in California)
Engine 4-Stroke SOHC Twin Cylinder
Displacement 999 cc
Bore x Stroke (mm) 93 mm x 73.5 mm
Vehicle Charging
System Output
660 W @ 3000 RPM or
900 W @ 3000 RPM (if equipped)
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition Timing ECU Controlled
32° +/- 2° @ 5000 RPM
Spark Plug/ Gap Autolite® 5684 / 0.85 mm Nominal
Lubrication System Wet Sump
Cooling Liquid
Front Suspension Dual A-Arm, IFS 10.0 in (25.4 cm) Travel
Rear Suspension Dual A-Arm, IRS 10.0" (25.4 cm) Travel
Ignition System Digital CDI
Driving System
Type
PVT
Shift Type Single Lever (H/L/N/R/P)
Gear Reduction -
Low
Front 8.56:1/ Rear 25.59:1
Gear Reduction -
Reverse
Front 7.67:1 / Rear 22.92:1
Gear Reduction -
High
Front 4.03:1 / Rear 12.05:1
Drive Ratio - Front 3.82:1 (non-EPS)
3.25:1 (EPS)
Tire Size - Front Standard Models: 25 x 10-12 NHS; 489
138
SPECIFICATIONS
