SPECIFICATIONS
See your Polaris dealer for jetting and clutching specifications.
RANGER 4x4 RANGER 6x6
Gross Vehicle Weight 2700 lbs. (1226 kg) 2900 lbs. (1317 kg)
Fuel Capacity 8.5 gal. (32.2 l) 8.5 gal. (32.2 l)
Towing Capacity 1500 lbs. (681 kg) 1500 lbs. (681 kg)
Max. Cargo Box Load 1000 lbs. (454 kg) 1000 lbs. (454 kg)
Overall Length 113 in. (282 cm) 120 in. (304.8 cm)
Overall Width (box) 60 in. (152.4 cm) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm) 58 in. (147.3 cm)
Overall Height 75 in. (190.5 cm) 75 in. (190.5 cm)
Wheelbase 76 in. (193 cm) 90 in. (228.6 cm)
Ground Clearance 7.2 in. (183 mm) 7.2 in. (183 mm)
Dry Weight 1185 lbs. (537 kg)(4x4)
1205 lbs. (547 kg)(NBU)
1410 lbs. (640 kg)
Cargo Box
(LxWxH)
58x42x10in.
(147 x 106.7 x 25.4 cm)
58x48x10in.
(147 x 122 x 25.4 cm)
Min. Turning Radius 132 in. (335.3 cm) 186 in. (472.4 cm)
Engine Oil Capacity 2qts.(2.1l) 2qts.(2.1l)
Coolant Capacity 2.25 qts. (2.4 l) 2.25 qts. (2.4 l)
Engine 4 valve 4 stroke single
cylinder with counter bal-
ance
4 valve 4 stroke single
cylinder with counter
balance
Displacement 499 cc 499 cc
Bore x Stroke 92x75 92x75
Pilot Jet 42.5 42.5
Main Jet 135 135
Needle Jet P-6 (829) P-6 (829)
Jet Needle 4MB32-3 4MB32-3
Air Screw 21/2 21/2
Alternator Output 250 W 250 W
Compression Ratio 10.2:1 10.2:1
Starting System Electric Electric
Carburetor 34 mm CV Mikuni 34 mm CV Mikuni
Ignition System CDI CDI
Ignition Timing 30_ @ 5000 rpm 30_ @ 5000 rpm
Spark Plug NGK BKR5E NGK BKR5E
