76
MAINTENANCE AND LUBRICATION
Filter Systems (RANGER 2x4, 4x4, 6x6)
Air Filter Service
We recommended that the air filter be replaced annually. When
operating in extremely dusty conditions, it should be replaced more
often.
1. Lift the cargo box to access the
airbox.
2. Remove the airbox cover and
inspect the gasket. It should
adhere tightly to the cover and
seal all the way around.
3. Remove the air filter (1).
4. Do not attempt to clean the main
element. Instal l a new air filter.
NOTE: Apply a small amount
of general purpose grease to the
sealing edges of the filter before
installing.
5. Inspect the air box for oil or water deposits. If present, drain them
into a suitable container.
NOTE: Service the air filter more frequently if the vehicle is operated
in wet conditions or at high throttle openings for extended periods.
