5. Slowly adjust the pedal adjuster in a 1/4 turn at a tie until the full engine
throttle IS obtained. Once proper adjustment is obtained, tighten jam nut in
place to hold the adjustment position.
TORQUE
Throttle Pedal Adjuster Jam Nut
19 Nm (14 ft-lbs)
6. With the unit in park, start the unit. Ensure the engine idle is still within range
of 1200 +/- 100 RPM. Fully depress the throttle pedal and ensure that the
engine RPM gets to 3850 +/- 50 RPM.
CAUTION
DO NOT HOLD hold the unit wide open for more than 10 seconds.
131
MAINTENANCE
