HITCHES
WARNING
Whenever the vehicle is towing, always stay clear of the area between the
vehicle and the towed object.
REAR HITCH
Use the rear hitch for towing a trailer.
REAR HITCH SPECIFICATIONS
Material S355J2+N
Fasteners Metal pin with security cotter pin
Weld Length and Positions 7 mm fillet, all around
Maximum Vertical Load 100 kg applied on coupling point
Maximum Towable Mass 1000 kg
Approval # E9-55R-01.6126
REAR HITCH CERTIFICATION LABEL
The hitch certification label is located near the hitch on models equipped with a
factory-installed rear hitch.
41
FEATURES AND CONTROLS
