47
OPERATION
Towing Loads
Towing improperly can alter vehicle handling and may cause loss of control or brake
instability. Always follow these precautions when towing:
1. Never load more than 68.1 kg (150 lbs.) tongue weight on the towing bracket.
2. Always operate in low gear and engage ADC 4X4 (if equipped) when transporting heavy
loads and/or when towing.
3. When towing a disabled RANGER vehicle, place the disabled vehicle’s transmission in
neutral. Do not operate the vehicle faster than 16 km/h (10 MPH) when towing.
4. Do not operate the vehicle faster than 16 km/h (10 MPH) when towing. See page 46.
Towing a trailer increases braking distance.
5. Do not tow more than the recommended weight for the vehicle. See the towing capacity
chart below and the specifications charts beginning on page 90.
6. Attach a trailer to the trailer hitch bracket only. Do not attach a trailer to any other
location or you may lose control of the vehicle.
7. Never tow a trailer on a grade steeper than 15°.
Belt Life
To extend belt life, use the lowest gear possible when hauling or towing heavy cargo.
Towing a RANGER
Towing this vehicle is not recommended. Always transport the vehicle on a trailer or flatbed
with all four wheels off the ground. See page 89.
If towing a disabled vehicle is unavoidable, place the disabled vehicle’s transmission in neu-
tral. Tow the shortest distance possible. Do not operate faster than 10 MPH (16 km/h).
Model Total Towed
Load Weight
(Level Ground)
Total Towed
Load Weight
(15° grade)
Total Hitch
Vertical
Weight
Maximum
Towing
Speed
RANGER 570 680.4 kg (1500 lbs.) 386 kg (850 lbs.) 68.1 kg (150 lbs.) 16 km/h (10 MPH)
