104
SPECIFICATIONS
* RANGER 4X4 models sold in California are designed and rated for a box capacity
of 600 lbs. (272 kg). The maximum weight capacity for these vehicles is 1100 lbs.
(499 kg).
RANGER 4X4
Maximum Weight Capacity* 1500 lbs. (681 kg) (includes weight of operator,
passenger, cargo, accessories)
Dry Weight 1237 lbs. (561 kg)
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 1.9 qts. (1.8 l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 1000 lbs. (454 kg)
Overall Length 114 in. (289.6 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 76 in. (193 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 158 in. (401 cm)
Engine 4 valve 4 stroke twin cylinder with counter
balance
Displacement 760 cc
Bore x Stroke 80 x 76.5
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10.0:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System Bosch EFI ECU Controlled
Spark Plug / Gap RC7YC3 /.035 in. (0.9 mm)
Front Suspension Dual A-arm w/9.6 in. (24.4 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
