106
SPECIFICATIONS
RANGER 6X6
Maximum Weight Capacity 2000 lbs. (907 kg) (includes weight of operator,
passenger, cargo, accessories)
Dry Weight 1551 lbs. (703.5 kg)
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 2000 lbs. (907 kg)
Max. Cargo Box Load 1250 lbs. (567 kg)
Overall Length 137 in. (348 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 105 in. (267 cm)
Cargo Box Dimensions (Inside) 42.5 x 54 x 11.5 in. (108 x 137 x 29 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 243 in. (617 cm)
Engine 4 valve 4 stroke twin cylinder with counter
balance
Displacement 760 cc
Bore x Stroke 80 x 76.5
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10.0:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System Bosch EFI ECU Controlled
Spark Plug / Gap RC7YC3 /.035 in. (0.9 mm)
Front Suspension Dual a-arm w/9.6 in. (24.4 cm) of travel
Center Suspension Independent w/9 in. (23 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
