108
SPECIFICATIONS
RANGER CREW
Maximum Weight Capacity 1750 lbs. (795 kg) (includes weight of operator,
passengers, cargo, accessories)
Dry Weight 1495 lbs. (678 kg)
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 1.6 gal. (6 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load 1000 lbs. (454 kg)
Overall Length 145 in. (368 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 108 in. (274 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 11.5 in. (29 cm)
Min. Turning Radius 255 in. (648 cm)
Engine 4 valve 4 stroke twin cylinder with counter
balance
Displacement 760 cc
Bore x Stroke 80 x 76.5
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10.0:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System Bosch EFI ECU Controlled
Spark Plug / Gap RC7YC3 /.035 in. (0.9 mm)
Front Suspension Dual a-arm w/9.6 in. (24.4 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
