63
MAINTENANCE
Drive Chain Slack Adjustment
1. Loosen the four rear housing
mount bolts (two on each side).
2. Loosen the chain adjuster lock
nuts.
3. Turn the chain adjusters clockwise
to 1/4"-1/2" (6-12 mm) deflection.
4. Tighten the chain adjuster lock
nuts to 18 ft. lbs. (25 Nm). Hold
the adjuster stud securely while
tightening the nut to avoid break-
ing the stud.
5. Tighten the four rear housing
mount bolts to 43 ft. lbs. (60 Nm).
Housing Mount Bolts
Chain Adjusters
