FILTER SYSTEMS
AIR FILTER REPLACEMENT
Inspect the air filter at the intervals outlined in the Periodic Maintenance Chart.
In extremely dusty conditions, air filter replacement will be required more often.
1. Tilt the rear cargo box to access the airbox.
2. Release the five airbox cover latches and lift the cover up and out to access
the air filter element.
3. Remove the air filter element
q
.
4. Inspect the airbox for oil or water deposits. Wipe away any deposits with a
clean shop towel.
NOTICE
If the filter has been soaked with fuel or oil it must be replaced.
DO NOT attempt to clean the air filter.
5. Place the air filter into the airbox. Reposition the lower airbox cover and
install the three retaining latches.
NOTICE
Make sure the hinge pins are properly seated when reassembling the airbox
135
MAINTENANCE
