9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
2.21
4. Remove the spark plug wires (D) from the engine.
5. Remove the (4) T40 bolts (E) and rubber isolators (F)
retaining the valve cover (G). Note the location and
use of the grounding washer (H) for assembly.
NOTE
Replace rubber isolators (F) upon assembly.
6. The engine will need to be rotated (4) times to
inspect all (8) valve clearances. Two valves can be
measured at each camshaft lobe position.
NOTE
Remove spark plugs to aid engine rotation.
7. Rotate the drive clutch counter-clockwise until the
cam lobes above the valves you are inspecting are
facing up.
MAINTENANCE
