7. Remove the thermostat cover (B), seal (D) and
thermostat (E) from the engine.
NOTE
Thermostat has a pop-off relief to allow the bypass
system to operate until thermostat opens.
8. Clean thermostat mating surfaces on the engine and
thermostat cover.
9. Install a new thermostat and seal into the cover and
install the cover onto engine.
10. Install the thermostat cover bolts and torque the bolts
to specification.
TORQUE
Thermostat Cover Bolts:89 ± 9 in-lbs (10 ± 1 Nm)
11. Install coolant hose back on the thermostat cover
and securely tighten the hose clamp.
12. Fill cooling system and proceed to “Cooling System
Bleeding Procedure” provided in this chapter.
