WHEEL TOE ALIGNMENT
1. Hold tie rod end to keep it from rotating.
2. Loosen jam nuts at both end of the tie rod.
3. Shorten or lengthen the tie rod until alignment is as required to achieve the
proper toe setting as specified in above.
IMPORTANT
When tightening the tie rod end jam nuts, the rod ends must be held parallel to
prevent rod end damage and premature wear. Damage may not be
immediately apparent if done incorrectly.
4. After alignment is complete, torque jam nuts to specification.
TORQUE
Tie Rod Jam Nut:
13 ft-lbs (18 N·m)
112
MAINTENANCE
