DRIVETRAIN
Transmission Type
Automatic CVT F/N/R
Transmission
Fluid Type / Fluid Capacity
Polaris AGL
25 oz (750 mL)
Drive Chain - Type / # Links
50 x 55
STEERING / SUSPENSION
Toe Out
0-1/8 in. / 0-3.2mm 0-1/8 in (0-3.2 mm)
Front Suspension
Coil-Over Shocks
Front Travel
7.0 in (17.8 cm)
Rear Suspension
Coil-Over Shocks
Rear Travel
7.0 in (17.8 cm)
Shock Preload Adjustment
Cam Adjustable
(Factory Setting -Softest)
WHEELS / BRAKES
Front Wheel Size
12 x 6 Stamped Steel
Front Tire Brand/Size/Load
Rating/Speed Rating
CST 24 x 8-12 38B
Rear Wheel Size
12 x 8 Stamped Steel
Rear Tire Brand/Size/Load
Rating/Speed Rating
CST 24 x 10-12 45B
Tire Air Pressure
Front
5 psi (34,5 kPa)
Rear
5 psi (34,5 kPa)
Brakes
Front Wheel Hydraulic Disc
Rear Axle Hydraulic Disc
Brake Fluid Polaris DOT 4 Brake Fluid
CLUTCH SETTINGS
ALTITUDE
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
Meters
(Feet)
0-3000
(0-10,000)
No changes for high altitude.
131
SPECIFICATIONS
