7.2
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS
ITEM SPECIFICATION
Ball Joint Pinch Bolts (Front) 23 ft-lb (31 Nm)
Bearing Carrier Nuts (Rear) 40 ft-lb (54 Nm)
Brake Caliper Mounting
Bolts (Front)
30 ft-lbs (41 Nm)
Brake Caliper Mounting
Bolts (Rear)
44 ft-lbs (60 Nm)
Brake Line Junction Block
Mounting Screws
36 in-lbs (4 Nm)
Clutch Cover (Outer)
Screws
100 in-lbs (12 Nm)
Drive Clutch Cover Plate
Screws
100 in-lb (12 Nm)
Front Gearcase Mounting
Bolts
30 ft-lbs (41 Nm)
Front Hub Castle Nut
80 ft-lb (108 Nm)
Rear Hub Castle Nut
110 ft-lbs (149 Nm)
Tie Rod End Fastener
43 ft-lb (58 Nm)
Wheel Lug Nuts
Steel Rims: 27 ft-
lbs (37 Nm)
Aluminum Rims:
30 ft-lbs (41 Nm) +
90°
SPECIAL TOOLS
PART NUMBER
TOOL DESCRIPTION
2872608 Roll Pin Removal Tool
8700226
CV Boot Clamp Pliers
(earless type)
PU-48951
Axle Boot Clamp Tool
Bosch Automotive Service Solutions – 1-800-328-6657
or http://polaris.service-solutions.com/
FINAL DRIVE
