8.14
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
22. Insert lower A-arm ball joint end into the bearing
carrier. Install lower ball joint pinch bolt (E) into the
bearing carrier and torque bolt to specification.
WARNING
Upon A-arm installation completion, test vehicle at low
speeds before putting into service.
23. Install front wheel. Torque wheel nuts to
specification.
TORQUE
Wheel Nuts:
Steel Rims: 27 ft-lbs (37 Nm)
Aluminum Rims: 30 ft-lbs (41 Nm) + 90°
STEERING / SUSPENSION
