9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
3.15
19.Install the water pump cover and three retaining bolts
i
. Torque bolts in sequence to specification.
TORQUE
Water Pump Cover Bolts:
7 ft-lb (10 Nm) (Apply Loctite® 204™ to bolt
threads)
20.Install two new water pump o-rings and lubricate
them with clean engine oil.
21.Install water pump assembly into the engine. (see
Chapter 3 – Water Pump Installation page 3.16)
ENGINE / COOLING SYSTEM
