9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
9.35
42.Push needle out of shock shaft using a metering rod
and Hex T-handle wrench.
43.Remove O-ring from needle.
44.Back out rebound adjuster with flat head screw driver.
45.Keep a magnet close to catch ball and spring when
the round adjuster is almost out.
46.Remove dust boot.
47.Remove both retaining rings from the eyelet and
press out bearing.
STEERING / SUSPENSION
