Polaris RZR S 900 EPS 2018

11
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
11.15
REAR CARGO BOX / FENDERS
q
RH Fender
u
Air Intake Cover
w
RH Fender Flair (50″ model has smaller flair)
i
Engine Access Panel
e
LH Fender
o
Bumper Bracket
r
LH Fender Flair (50″ model has smaller flair)
a
T27 Torx Screws
8 ft-lb (11 Nm)
t
Rear Bumper
s
Plastic Rivets
y
Cargo Box
BODY / FRAME
