Polaris RZR XP4 1000 2018 User Manual

1.10
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
ITEM
TORQUE
Stator Cover Screws
9 ft-lb (12 Nm)
Starter Solenoid Cable Fasteners
35 in-lb (4 Nm)
Steering Tilt Shock Fastener 7 ft-lb (10 Nm)
Steering Pivot Tube Fasteners 8 ft-lb (11 Nm)
Steering Rack Mounting Bolts 16 ft-lbs (22 Nm)
Steering Shaft to EPS Unit 15 ft-lbs (20 Nm)
Steering Shaft to Steering Rack 42 ft-lb (57 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Thermostat Cover Bolts
7 ft-lb (10 Nm)
Throttle Pedal Fastener Nuts
8 ft-lb (11 Nm)
Tie Rod End to Knuckle
30 ft-lb (41 Nm) + 90°
Tie Rod Jam Nuts
14 ft-lbs (19 Nm)
Trailing Arm to Frame 70 ft-lb (95 Nm)
Trailing Arm to Bearing Carrier
Fasteners
42 ft-lb (54 Nm)
Trans Bell Crank Nut
18 ft-lb (24 Nm)
Trans Case Screws
20 ft-lbs (27 Nm)
Trans Drain / Fill Plugs 14 ft-lbs (19 Nm)
Trans Isolator Bolt (rear) 40 ft-lb (54 Nm)
Trans Rear Mount Bracket Fasteners
22 ft-lb (30 Nm)
Trans Joint Bracket Bolts
44 ft-lb (60 Nm)
Trans Park Flange Screws 10 ft-lb (14 Nm)
Trans Sector Gear Cover
12 ft-lb (16 Nm)
Trans Shift Fork Screws
10 ft-lb (14 Nm)
Trans Snorkel Tube Locking Screw 10 ft-lb (14 Nm)
Valve Cover Bolts
7 ft-lbs (10 Nm)
Visor Mounting Screws 8 ft-lb (11 Nm)
Voltage Regulator Fasteners 5 ft-lb (7 Nm)
Water Pump Impeller
7 ft-lb (10 Nm)
(Apply Loctite®
204™ to bolt
threads)
Water Pump Cover Bolts
7 ft-lb (10 Nm)
(Apply Loctite®
204™ to bolt
threads)
Wheel Lug Nuts 120 ft-lbs (163 Nm)
GENERAL INFORMATION
