5. If removing the rear wheel, place wheel chocks at the front of both front
wheels to prevent rolling.
6. Elevate the vehicle until the wheel is slightly off the ground.
7. Remove the wheel nuts and remove the wheel.
WHEEL INSTALLATION
1. With the transmission in gear and the park brake set, place the wheel on the
wheel hub. Be sure the valve stem is toward the outside and rotation arrows
on the tire point toward forward rotation.
2. Install the wheel nuts and finger-tighten them.
NOTICE
On vehicles with tapered wheel nuts, make sure the tapered end of the nut
goes into the taper on the wheel.
3. Tighten all wheel nuts in a star pattern to specification.
TORQUE
75 ft-lbs (102 Nm)
4. Lower the vehicle and remove the floor jack.
SPARK PLUGS
SPARK PLUG RECOMMENDATIONS
Refer to the Specifications section for the recommended spark plug type and
gap for your vehicle. Torque spark plugs to specification after installing.
NOTICE
Using non-recommended spark plugs can result in serious engine damage.
Always use the recommended spark plugs.
SPARK PLUG SPECIFICATIONS
Spark Plug Type NGK ZMR7A-10
Spark Plug Torque 9 ft-lbs (12 Nm)
Inspect and replace spark plugs at the intervals recommended in the Periodic
Maintenance Chart section. Inspect spark plugs when the engine is warm.
Always replace spark plugs in sets of four.
124
MAINTENANCE
