CLUTCH
6.1
SPECIAL SERVICE TOOLS AND SUPPLIES
Description Part Number
Drive Clutch Puller 2870506.........................
Clutch Holding Fixture 2871358.....................
Spider Removal Tool 2870341.......................
Offset / Alignment Tool (Std) 2870654................
Driven Clutch Puller 2870913.......................
Spider Pin Tool 2870910............................
Clutch Bushing Removal & Installation 2871226.......
Piston Pin Puller (Used with 2871226) 2870386........
EBS Offset / Alignment Tool 2872292................
EBS Clutch Bushing Tool Kit 2201379................
Loctitet 680 2870584.............................
RTV Silicone Sealer 2870661.......................
Loctite Gasket Remover 2870601....................
PVT SYSTEM FASTENER TORQUES
Drive Clutch Retaining Bolt 40 ft. lbs..................
Driven Clutch Retaining Bolt 17 ft. lbs.................
PVT Inner Cover Bolts 12 ft. lbs......................
Drive Clutch Spider (Standard Clutch) 200 ft. lbs.........
(EBS Clutch) 185 ft. lbs............
Drive Clutch Spider Limiter Nut (EBS) 5 ft. lbs.........
Drive Clutch Cover Plate 90 in. lbs....................
