SPORTSMAN 6X6 570
SPORTSMAN® 6X6 570
Maximum Weight Capacity 1115 lbs. (505.8 kg) (includes operator,
passenger, cargo, accessories)
Dry Weight 1095 lbs. (496.7 kg)
Fuel Capacity 6.25 gal. (23.7 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2.7 qts. (2.5 l)
Rear Gearcase Oil Capacity 7.1 oz. (210 ml)
Demand Drive Fluid Capacity 9 oz. (265 ml)
Transmission Oil Capacity 33.8 oz. (1000 ml)
Front Rack/Storage Box Capacity 90 lbs. (40.8 kg)
Rear Rack Capacity 180 lbs. (81 kg)
Cargo Box Capacity 800 lbs. (362 kg)
Hitch Tongue Weight 150 lbs. (68 kg) (Rear box capacity and tongue
weight not to exceed 400 lbs./181 kg)
Hitch Towing Rating 1500 lbs. (680 kg)
Unbraked Trailer Towing Capacity (Based on
EU Directive 76/432/EC)
2127 lbs. (964 kg)
Overall Length 116 in. (294 cm)
Overall Width 49 in. (124 cm)
Overall Height 49 in. (124 cm)
Wheelbase 84 in. (213 cm)
Ground Clearance 11.5 in. (29 cm)
Minimum Turning Radius 160 in. (406 cm) (unloaded)
Rear Gearcase Oil Capacity 5 oz. (150 ml)
Engine Dual overhead cam, 4 valve 4 stroke single
cylinder
Displacement 567 cc
Bore x Stroke 99mm x 73.6mm
160
SPECIFICATIONS
