THE PERFECT FIT
Handlebar Adjustments
Handlebar Position
1. Loosen the four bolts on
the bottom of the adjuster
block. If necessary, pry the
blocks apart with a screw-
driver.
2. Adjust the handlebar for-
ward or rearward to the
desired position.
3. Tighten the bolts. Torque
the bolts to 13-16 ft. lbs.
(18-22 Nm).
Handlebar Angle
1. Loosen the four bolts on
the top of the adjuster
block. If necessary, pry the
blocks apart with a screw-
driver.
2. Adjust the handlebar for-
ward or rearward to the
desired angle.
3. Tighten the bolts. Torque the bolts to 13-16 ft. lbs. (18-22 Nm).
Loosen top bolts to adjust
handlebar angle
Loosen bottom bolts to
adjust handlebar position
