105
SPECIFICATIONS
2004 Trail Boss
Capacities
Body Style Gen IV
Gross Vehicle Weight 845 lbs. (383 kg)
Fuel Capacity 3.25 gal. (12.35 l)
Transmission Oil 11.3 oz. (335 ml)
Engine Oil Capacity 1.9 qts. (1.8 l)(incl. oil cooler )
1.7 qts. (1.6 l)(oil change only)
Front Rack 75 lbs. (34.1 kg)
Rear Rack 125 lbs. (56.7 kg)
Tongue Weight 85 lbs. (38.6 kg)
Hitch Towing Rating 850 lbs.(386 kg)
Unbraked Trailer Towing Capacity* 1263 lbs. (573 kg)
Turn Radius 75 in. (190.5 cm)
Ground Clearance 5.5 in. (14 cm)
Height 46 in. (116.8 cm)
Length 75 in. (190.5 cm)
Width 46 in. (116.8 cm)
Seat Height 34 in. (86.4 cm)
Dry Weight 505 lbs. (229 kg)
Wheel Base 49.5 in. (125.7 cm)
Engine & Cooling
Engine Model Number / Type ES-32PFE-102 / 4 Cycle, Single Cylinder
Lubrication Wet Sump
Bore x Stroke 78.5 x 68
Displacement 329
Compression Ratio 9.2/1
Engine Cooling Air with fan assisted oil cooler
Alternator Output (watts) 200w @5000 rpm
Carburetion BST34
Main Jet 122.5
Pilot Jet 42.5
Needle Jet P-0 (829)
Pilot Air Jet 160
Pilot Screw 2.0+ turns
Jet Needle 4HB48-2
Ignition DC CDI
Timing 30°±2° @ 5000 RPM
SparkPlugType/Gap BKR6E / .036 in. (.9 mm)
* Based on EU Directive 76/432/EC
