90
MAINTENANCE AND LUBRICATION
Lights
When servicing a halogen l amp, don’t touch t he lamp with bare
fingers. Oil from your skin leaves a residue, causing a hot spot that
will shorten the life of t he lamp.
Headlight Lamp Replacement
1. Remove the wire harness connector from the back of the headlight.
2. Grasp the bulb housing and turn it counterclockwise to rem ove the
bulb.
3. Apply dielectric grease to the light bulb socket before installing a
new bulb. Install the replacement bulb into the headlight housing
and rotate clockwise firmly. NOTE: The bulb must be positioned
so the harness installs into the lamp at the bottom.
4. Reinstall the connector to the back of the headlight..
High Beam Adjustment
The headlight beam can be adjusted vertically.
1. Position the ATV on a level surface with the headlight
approximately 25 ft. (7.6 m) from a flat wall.
2. Measure the distance from the floor to the center of the headlight
and make a mark on the wall at the same height.
3. Start the engine and t urn the headlight switch to high beam.
4. Observe the headlight aim on t he wall. The most intense part of
the headlight beam should be aimed 2” (5.1 cm) below the mark
placed on the wall. NOTE: Include rider weight on the seat when
measuring.
5. Loosen the pivot bolt and adjust the beam to the desired position.
6. Tighten the bolt and torque to 60 in. l bs.
WARNING
Poor lighting while driving can result in severe injury or death.
Headlight and taillight lenses become dirty during normal operation.
Wash the headlights frequently to maintain lighting quality.
Hot components can cause serious burns to skin. Do not service
the headlamps until they’ve cooled sufficiently.
