28
Framing and focusing the image
Before attempting to capture an image with the DMC
camera, view the subject through the microscope eyepiece
and adjust its position, focus and lighting according to the
microscope instructions.
When the subject appears as desired in the microscope
eyepiece, continue to the following section.
Selecting picture options
After adjusting the image through the microscope eyepiece,
view the black-and-white viewfinder image in the main DMC
window on your computer display. You can then choose the
optimum picture options as described below.
Note: If a viewfinder image is not visible on your computer
display, click the Preview button. You may also need to
adjust shutter speed or film speed as described below to
make an image visible.
PC window:
dmcmain3.bm
