Polaroid FLM-3232 - Using Picture-In-Picture (PIP)

ENGLISH
27
Chapter 3 Using the LCD TV
The PIP/POP feature allows simultaneous viewing of video from two sources (TV, VCR, DVD etc).
Only one source’s audio is played at a time; the user may select which source’s audio is heard.
 Press the PIP button once to enter picture in picture mode.
Main
Sub
MAINSUB
Using Picture-In-Picture
▪ Press ◄ ► to toggle the audio source between the main window and
the sub window.
▪ Press the OK button to change the position of the second window.
1
3
5
2
4
▪ Press ◄ ► to activate either the main or sub window, then press the Input
button to display the Input List:
Sub
TV(CABLE/AIR)
VIDEO1 (SIDE)
VIDEO2 (REAR) 
VIDEO3 (S-VIDEO)
VIDEO4 (YPbPr1)
VIDEO5 (YPbPr2)
COMPUTER (VGA)
▪ Press ▲▼ to change input source and press the OK button.
Chapter 3
USING THE FEATURES
