Polaroid MiniPortrait 203 Repair Manual

10
Section 3 - Reassembly of Exposure
Mode Change Gears
Note: Disassembly procedures are basically similar for both the 203 and 403
Miniportrait Cameras. See Section 3 of the Miniportrait 403 Repair Manual.
1. Remove Gear 1 and turn Gear (2) until tip A of the switch contact aligns with the
third tooth of Gear (2). (Figure 8.)
2. Now, turn the pin Gear (a) and engage it with Gear (1), so that the pin on Gear (a) is
in line with gear post (3) (dotted line B).
Figure 8. Reassembly of exposure mode change gear
