42
TFT screen size
8 inches (16：9)
Screen resolution 480x234
Laser Wavelength 780/650nm
Video System NTSC
Frequency Response 20Hz-20kHz ±2.5dB
Audio Signal-to-noise Rate ≥85dB
Audio distortion + noise ≤ -70dB (1kHz)
Channel Separation ≥70dB (1kHz)
Dynamic Range ≥80dB (1kHz)
Audio Out Out Level 2V±
0.2
1.0
, Load 10kΩ
Video Out
Out Level 1V
P-P
±0.2, Load 75Ω
Unbalanced Negative
Power AC100～240V（50Hz/60Hz）
Dimensions 205mm x 153mm x 41mm
Weight Approximate 1.12 Kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
© 1992 -1997 Dolby Laboratories, Inc.
All rights reserved.
Specifications
