42
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
TFT screen size 7 inches
Laser Wavelength 780/650 nm
Video System NTSC
Frequency Response
20Hz～20kHz ±2.5dB
Audio Signal-to-noise Rate
≥85dB
Audio distortion+noise
≤－70dB (1kHz)
Channel Separation
≥70dB (1kHz)
Dynamic Range
≥80dB (1kHz)
Audio Out Analog Audio Out
Out Level: 1.5V±
0.2
1.0
, Load: 10KΩ
Video Out Video Out
Out Level: 1V
P-P
±0.1, Load: 75Ω
Unbalanced Negative
Power
AC 100-240V ～ 50/60Hz
Power Consumption < 25W
Dimensions 195mmX149mmX38.5mm (L*W*D)
Weight About 1.2 kg
Compliance with FCC, FDA - cUL listed E209155
Specifications
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works. © 1992 -1997 Dolby Laboratories.
All rights reserved.
