-2-
En
Thank you for buying this 35mm power zoom camera. Before using, please
read the manual carefully to ensure correct use.
Attaching the Wrist Strap
1. Thread the small loop end of the strap through the Wrist-Strap Eyelet.
(Fig.1)
2. Pass the other end of the strap through the small loop. (Fig. 2)
3. Securely tie the strap onto the eyelet. (Fig. 3)
Loading the Batteries
1. Open the Battery Compartment by sliding the Battery Compartment Door in
the direction of the arrow. (Fig. 4)
2. Gently lift up on the Battery Compartment Door. (Fig. 5)
3. Insert two AA alkaline batteries into the battery
compartment, checking that the (+) and (-) on
the batteries are aligned according to the polarity
indication shown on the contact plate. (Fig. 6)
4. Close the Battery Compartment Door and slide
it back until it latches. (Fig. 7)
Fig.6
Fig.2
Fig.3
Fig.5
Fig.1
Fig.4
Fig.7
515982-00-EN 2 8/12/04, 1:48:12 PM
