Rear of TV
Connecting an A/V Device with Composite Connector
Use a composite cable to connect the external A/V device’s composite video/audio jacks to
the LCD TV’s VIDEO IN jacks.
Connect all AC power sources, before turning on the power switch of the LCD TV or
other connected equipment.
Press the button on the remote to turn on the LCD TV.
To view the A/V device’s with component input, press the INPUT button on the remote to
select AV.
GAME CONSOLE
DVD PLAYER
Not all A/V devices have the ability to connect to a TV. Please check your A/V devices
user guide for compatibility.
18
Chapter 2 Installing the LCD TV
AUDIO Cable
L
R
VIDEO OUT
AV Cable
To Next Page
