Page 9
I
I
6. Definition of units/conversions
1˝ = 25.4mm
1mm = .0394˝
1cm = 10mm
1cc = 1 mL = .0338 oz. (fluid)
1 oz. (fluid) = 29.565 mL
1 oz. (weight) = 28.35 grams
1 gram = .035 oz. (weight)
1 liter = 1.057 quarts = 2.114 pints = 4.228 cups
1Nm = .102 m/kg
1m/kg = 9.804 Nm
1 lb. = 2.2 kg
1 ft/lb = 1.357 Nm = .1383 m/kg
1 barrel (beer) = 31 gallons
1 kilometer = .621 miles
To covert degrees Fahrenheit to Celsius: subtract 32 and divide by 1.8
To convert degrees Celsius to Fahrenheit: multiply by 1.8 and add 32.
For any other conceivable conversions you might need, consult www.onlineconversion.com
7. Torque values
Alternator nut ..............................42 ft/lbs (57Nm)
Brake rotor bolts ..........................
Case bolts ....................................7 ft/lbs (10 Nm)
Clutch nut ....................................42 ft/lbs (57Nm)
Cylinder nuts................................10 ft/lbs (13.6 Nm)
Engine mount bolt (front)............42 ft/lbs (57Nm)
fork pinch bolts............................11 ft/lbs (15 Nm)
Front axle ....................................37 ft/lbs (50 Nm)
Front axle pinch bolt....................18 ft.lbs (25 Nm)
Fork cap ........................................4 ft/lbs (5 Nm)
Fork slider retaining bolt ............20 ft/lbs (27.1Nm)
Fuel tank screw............................snug by hand only
Handlebar clamps ........................18 ft.lbs (25 Nm)
Lower shock nut ..........................33 ft/lbs (45 Nm)
Rear axle nut................................37 ft/lbs (50 Nm)
seat bolt........................................snug by hand only
Spark plug....................................20 ft/lbs (27.1Nm)
Sprocket bolts ..............................
Steering stem adjusting nut..........adjust by hand until play is gone
Steering stem top nut ..................18 ft.lbs (25 Nm)
Swingarm nut ..............................37 ft/lbs (50 Nm)
Upper shock nut ..........................33 ft/lbs (45 Nm)
General torque values for fasteners not listed above
bolt size hex head size Socket head size ft/lb m/kg Nm
5mm bolt . . . . .XXmm head . . . . . . . . . . . . . . . . .3.6ft/lb . ..5m/kg . . . .5Nm
5mm screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.9ft/lb . .4m/kg . . . . 4Nm
6mm bolt . . . . .10mm head . . . .5mm . . . . . . . . . .7ft/lb . . .1m/kg . . .10Nm
6mm screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6.5ft/lb . ..9m/kg . . . .9Nm
8mm bolt . . . . .12mm head . . . .6mm . . . . . . . . . .16ft/lb . .2.2m/kg . . 22Nm
10mm bolt . . . .14mm head . . . . . . . . . . . . . . . . . . .25ft/lb . .3.5m/kg . . .35Nm
12mm bolt . . . .17mm head . . . . . . . . . . . . . . . . . . .40ft/lb . .5.5m/kg . . .55Nm
14mm bolt . . . .19mm head . . . . . . . . . . . . . . . . . . .61ft/lb . .8.5m/kg . . .85Nm
16mm bolt . . . .22mm head . . . . . . . . . . . . . . . . . . .94ft/lb . .13m/kg . .130Nm
note: bolt size refers to thread size, not the wrench size used on head of bolt!
bolt head sizes are for standard hardware, use torque values in service sections if provided.
5
6
8
10
12
14
16
Actual bolt sizes
