OWNER′S MANUAL

SETUP INSTRUCTIONS

Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.

Site Preparation

• Select a level area, and completely remove all debris, twigs, stones, etc. DO NOT select an area under overhead electrical lines, trees, or within 15 feet of a house,

building, etc.

• The pool shall be located a minimum distance of 6ft (1.83m) from any electrical receptacle.

• All 125 volt, 15 and 20 ampere receptacles located within 20ft (6.0m) of the pool shall be protected by a ground fault circuit interrupter (GFCI).

The 20ft (6m) distance is measured via the shortest straight line distance the supply cord would follow without piercing a floor, wall, ceiling, doorway, window, or

other permanent barrier.

• Contact your local utilities, checking that no underground cables, telephone lines, gas lines, etc. run beneath the area you have selected.

WARNING - DO NOT overfill the pool and / or allow people to lay over or sit on pool wall - DOING SO CAN CAUSE PERMANENT INJURY!

DRAIN pool to the proper level after a heavy rain. The Maximum Water Level FILL LINE is printed on the pool liner.

TIP: It will be much easier to install your pool if you unfold it and let it lay in direct sunlight for about 2 hours prior to installation. This will help to ensure a

wrinkle-free fit because the pool material will be more pliable allowing it to form into shape during installation.

WARNING - IMPORTANT! SITE MUST BE LEVEL, STABLE, COMPACTED SOIL.

• The pool must be assembled on a smooth and level site of firm soil that is free of stones, gravel, sticks, blacktop, or other oil base compounds.

• Before setting up your pool, it is recommended that you clear the area of hardy grasses. Certain types of vigorous grasses such as St. Augustine and

Bermuda can grow through the liner. A ground cloth or tarp may be helpful in preventing this from occurring. Grass growing through the liner is not covered

under warranty.

• Do not install pool on a wooden deck or any type of wooden surface. You cannot use sand and/or uncompacted soil to provide a level surface for this pool;

it will only wash out.

• FAILURE TO FOLLOW ALL OF THESE INSTRUCTIONS WILL CAUSE POOL TO COLLAPSE AND WILL VOID THE WARRANTY!

Setup Instructions Continued

Inflating Instructions

CAUTION: Inflate by adult only. DO NOT overinflate, use high pressure air compressor to inflate, or exceed the recommended Design Working Pressure. Inflate

with cold air only.

1. Locate a clean area free of stones or other sharp objects to inflate the pool.

2. Inflate the air chambers following the numbered sequence (if any) slowly with a manual/foot air pump.

The adequate air pressure: make sure the pool is firm to the touch but NOT hard – there should be small folds around the armrests, backrests and/or side

edges, and below the cup holders (if any). Also compare the pressure with that of the large main chamber.

3. Close and press the inflation valves into the unit to get a flat surface.

4. Check regularly to ensure the adequate air pressure during each use, especially on very hot or cold days.

FILL THE POOL WITH 1 INCH OF WATER. THEN, SMOOTH OUT THE WRINKLES FROM THE BOTTOM OF THE POOL BY BRUSHING OUTWARDS

FROM THE INSIDE OF THE POOL SO IT FILLS UP EVENLY. MAKE SURE THAT THE BASE OF THE POOL IS COMPLETELY FLAT AND LEVELED.

NOT FOLLOWING THIS STEP WILL MAKE THE POOL FILL UNEVENLY AND MAY LOOK MISSHAPEN. IF THE POOL IS UNEVEN, YOU MAY NEED TO

RESTART THE SETUP (FIGURE 2-3).

5. Pull all the outer walls up straight and make sure they are not under the pool floor. Also make sure to pull up the top ring, all around the pool, so that it fills evenly.

NOTE: IF MORE THAN 1-2 INCHES OF WATER COLLECTS ON ANY ONE SIDE BEFORE THE POOL STARTS FILLING IN THE CENTER, THE POOL IS

NOT LEVEL ENOUGH, AND MUST BE CORRECTED. SEE “SITE PREPARATION” ABOVE.

ADDITIONAL NOTE: THE WEIGHT OF THE WATER WILL MAKE ADJUSTMENT IMPOSSIBLE AFTER THIS POINT.

6. Now, as you continue filling, the inflated ring will rise as the water deepens. Once this is done, if your pool included a filter/pump system please refer back to

the “Swimming Pool Filter System” owner’s manual and follow all instructions for the installation of the filter pump.

1 2 3

Setup Instructions

1. Carefully unfold the Quick Set

pool and inspect the seams for manufacturing defects. With the inflatable ring on the top side, and safety writing on the outside lay

out the pool in the area selected, making sure the bottom of the pool is both flat and round.

2. If your pool included openings or you are going to purchase a filter pump system, position the Suction & Return fitting locations so they are 10 to 21 feet from the

electrical outlet you plan to use for the pool pump.

3. If your pool came with fittings, install both the Suction and Return fittings to the pool wall before filling the pool.

Please Note: The Black Rubber gasket (Gasket) should always be slid over the threaded plastic suction or return fitting and be on the inside before the fitting is

placed through the pool wall to make a watertight connection.

Make sure to put on both the Water Cap and the Service Plug while you fill your pool, or until you are ready to add a filtration system.

RETURN FITTING

Service Plug

Return Fitting

Gasket

Fitting Lock Nut

Snap-On

Return Fitting

Thrust Washer

Split Suction

Fitting Lock Nut
