PolyScience Refrigerated Recirculating Chillers User Manual

10
Specifications — 3/4-HP and 1-HP Chillers
Model: Rfg = Refrigerating Only
Rfg / Htg = Refrigerating & Heating
Magnetic Drive Centrifugal Pump
Model Rfg Rfg / Htg Rfg Rfg / Htg
Operating Temperature -10° to 40°C -10° to 70°C -10° to 40°C -10 to 70°C
Compressor 3/4 HP 1 HP
Cooling Capacity @ 20°C
10°C
0°C
2500 watts 8525 BTU/hr
1700 watts 5797 BTU/hr
760 watts 2591 BTU/hr
2900 watts 9889 BTU/hr
1950 watts 6649 BTU/hr
1000 watts 3410 BTU/hr
Pressure at 0 Flow Rate 10 psi / 69 kPa 10 psi / 69 kPa
Flow Rate at 0 psi 4.1 gpm / 15.5 lpm 4.1 gpm / 15.5 lpm
Reservoir Capacity 1.1 gal / 4.2 liters 1.1 gal / 4.2 liters
Dimensions (h x w x d)
22-5/8 x 14-1/2 x 27-5/8 in.
57.6 x 36.8 x 70.2 cm
Shipping Weight
187 pounds
84.8 kg
189 pounds
85.7 kg
208-230 V, 60 Hz
Volts Range 187 to 253V
Amps 9.2A 9.5A 9.5A 9.8A
240 V, 50 Hz
Volts Range
Over Voltage
198 to 264V
Category II
Amps 9.2A 9.5A 9.5A 9.8A
Positive Displacement Pump (“P” Series Chillers)
Model P Series Chillers Rfg Rfg / Htg Rfg Rfg / Htg
Operating Temperature -10° to 40°C -10° to 70°C -10° to 40°C -10° to 70°C
Compressor 3/4 HP 1 HP
Cooling Capacity @ 20°C
10°C
0°C
2500 watts 8525 BTU/hr
1700 watts 5797 BTU/hr
760 watts 2591 BTU/hr
2900 watts 9889 BTU/hr
1950 watts 6649 BTU/hr
1000 watts 3410 BTU/hr
Flow Rate @ 0 psi 3.5 gpm / 13.2 lpm 3.5 gpm / 13.2 lpm
Pump Pressure (adjustable)
20 to 100 psi
138 to 689 kPa
20 to 100 psi
138 to 689 kPa
Reservoir Capacity 1.1 gal / 4.2 liters 1.1 gal / 4.2 liters
Shipping Weight
197 pounds
89 kg
199 pounds
90 kg
208-230 V, 60 Hz
Volts Range 187 to 253V
Amps 11.9A 12.2A 12.2A 12.5A
240 V, 50 Hz
Volts Range
Over Voltage
198 to 264V
Category II
Amps 11.9A 12.2A 12.2A 12.5A
