28/POMCube
12in
16in
(6)
Install the bracket and battery system on the wall with
M6x50 tapping screws.
N
NOOTTEE: If you are installing it on a concrete wall, properly
drill into the wall with M6x50 tapping screws and plastic
anchors.
CAUTION: Dust collection is required durin
drilling.
CAUTION: Make sure the cabinet is firmly on th
floor. The wall bracket is only designed to kee
the battery system from tipping forward, no
supporting the weight of the battery.
7)
Hang the inverter on the bracket.
OOTTEE: Before installing Universal PCS, remove
he battery seal cap (BAT/COM) on the bottom
f Universal PCS.
