POMCube iCAN NetZero Plus - Internal Wiring

32/POMCube
(1)
Remove the screws from the access panel located at the top of the battery
cabinet. Remove the cover plate for wiring.
(2)
Connect battery system to Universal PCS with the ground wire.
(Torque: 3 N·m).
5.3 Internal Wiring
