08
Place compressor in an upright, level position on a stable, rigid surface
for proper operation.
Place compressor in a clean, dry, well-ventilated area.
The compressor must always be secured on a wall-mounted, fan-cooled shelf
or in a fan-cooled post-mount cabinet.
Use forced fan cooling in a ventilated building to ensure ambient room
temperature does not exceed 40°C (104°F). This will prevent overheating.
Compressor must be positioned at least 18 inches away from any
obstructions that prevent interference with cooling air flow.
Locate compressor as close to main power supply as possible to avoid using
long lengths of electrical wiring or extension cords.
The Inlet Filter must be kept clear of obstructions to avoid reducing air flow.
Air Compressor Placement
If any parts are damaged or missing, do not operate until parts are replaced.
Failure to follow this warning could result in serious personal injury.
Do not use compressor in an environment that is dusty or otherwise
contaminated. This type of environment may cause damage to compressor.
Always follow filter maintenance instructions (pg. 13)
Compressor Flow Data (CFM)
Amp Data
CA-55 CA-65
4.50
3.00
5.50
3.40
6.80
5.80
7.80
6.20
Pressure
CA-150CA-125
0
5
2.80
5.70 6.153.30
7.5
10
15
2.75 3.20 5.55 5.90
2.60 3.10 5.20 5.75
2.35
2.61
2.68
2.75
2.89
CA-55 CA-65
3.63
2.92
2.41
3.06
3.03
3.47
Pressure
CA-150CA-125
0
5
3.23 3.743.01
7.5
10
15
3.11 3.41 4.00
3.25 3.79 4.45
